Camera information
- Signal System: HDMI: 4KP30, 4KP29.97, 4KP25, 1080P60, 1080P50, 1080P30, 1080P25, 1080P29.97 etc.
- Sensor: 1/2.5 inches, CMOS, Effective Pixels: 8.51 Megapixels.
- Scanning Mode: Progressive.
- Lens: 12x, f=4.4mm-52.8mm, F1.8-F2.6.
- Digital Zoom: 16X.
- Minimum Illumination: 0.5Lux@ (F1.8, AGC ON).
- Shutter: 1/30s - 1/10000s.
- White Balance: Auto, Indoor, Outdoor, One Push, Manual.
- Backlight Compensation: Support.
- Digital Noise Reduction: 3D digital noise reduction.
- SNR: >55DB.
- Horizontal FOV: 71° - 8.2°.
- Vertical FOV: 42.7° - 4.5°.
- Pan Angle: ±170°.
- Tilt Angle: -30° - +30°.
- Pan Speed: 1.7°-76°/s.
- Tilt Speed: 0.5°-15°/s.
- Preset Position: 255.
- Network Interface: 1 x RJ45: 10M/100M/1000M adaptive Ethernet, supports PoE.
- Audio Interface: 1 x Line In/Mic In, 3.5mm Jack.
- Video Compression: H.265 / H.264 / MJPEG.
- Video Stream: First Stream, Second Stream.
- First Stream Resolution: 3840x2160, 1920x1080, 1280x720 etc.
- Second Stream Resolution: 720x480, 320x240 etc.
- Video Bit Rate: First Stream: 32kbps-51200kbps, Second Stream: 32kbps-20480kbps.
- Bit Rate Control: VBR, CBR.
- Frame Rate: 50Hz: 1fps-50fps, 60Hz: 1fps-60fps.
- Protocols: NDI®|HX2, SRT, TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, GB/T 28181, Multicast etc.
- Input Voltage: DC 12VDC / PoE 802.3 AF.
- Input Current: 1.0A.
- Operating Temperature: -0° C - 40° C.
- Storage Temperature: -40° C - 60° C.
- Power Consumption: 12W (Max)
Description
- 4K UHD: High quality 1/2.5 inches UHD CMOS sensor with 8.51 million pixels.
- 12X Optical Zoom: 12X optical zoom and 71-degree horizontal field of view, can cover the demand of extra large conferencing rooms.
- OLED Display: HDMI and SDI output resolution, IP address, and other information.
- Remote Control: Supports multiple ways of control like RS232, RS485, network, and USB.
- Multiple Interface: HDMI, USB, 3G-SDI (up to 150 meters transmission with 1080p 30), LAN.
